Wire Rope Hoist

Name: Wire Rope Hoist
Brand: SHIVAY ENGINEERING WORKS
Price: 50000 INR
Availability: InStock

Price 50000 INR/ Piece

Get a Price/Quote

MOQ : Any Order Piece

Wire Rope Hoist Specification

Surface Finish
Powder coated/painted for corrosion resistance

Hook
Heavy-duty forged steel, single/double as required

Frequency
50-60 Hz

Lifting Speed
3-8 m/min

Usage
Industrial

Power Source
Electric

Sling Type
Wire Rope

Size
Different Size Available

Maximum Lifting Weight
30 Ton

Maximum Lifting Height
6 meters to 40 meters

Product Type
Wire Rope Hoist

Lift Speed
3-8 m/min (model dependent)

Power
2 kW to 25 kW depending on model

Voltage
380V / 415V / 440V AC

Rotating Speed
1440 rpm

Insulation Grade
Class F

Trolley
Motorized, push travel or geared type

Capacity
0.5 Ton to 30 Ton

Gear Box
Totally enclosed, oil-lubricated

Motor Type
Squirrel cage induction motor with brake

Duty Cycle
Heavy duty / S4

Working Temperature Range
-10C to +55C

Brake Type
Electromagnetic fail-safe brake

Mounting Type
Fixed mounted / trolley mounted

Wire Rope Diameter
8 mm - 22 mm

Protection Level
IP54/IP55

Color
Black/Blue/Customizable

Control Method
Pendant control / Remote control optional

Limit Switches
Provided for over hoisting and lowering

Wire Rope Hoist Trade Information

Payment Terms
Cash Advance (CA)

Supply Ability
1 Piece Per Day

Delivery Time
7 Days

Main Domestic Market
All India

About Wire Rope Hoist

Wire Rope Hoist

Wire Rope Hoist is suitable for medium and heavy duty operations. Manufactured to be durable and highly efficient, it is complimented by custom engineered systems to meet every type of application requirements of our customers. It is designed in modular construction which greatly simplifies, repairs & cuts down - time. Our clientele can avail this Wire Rope Hoist at industry leading prices.

Advanced Industrial Lifting Solution

Designed for unwavering performance in demanding environments, our Wire Rope Hoist delivers power and precision. Its heavy-duty build, advanced motor and brake systems, and adaptable mounting and control options make it suitable for a host of industrial operations. Whether lifting light or heavy loads, the hoist always ensures operator safety and equipment longevity.

Customizable and Reliable Performance

Our hoists can be tailored to your operational requirements with multiple color options and mounting types. With a corrosion-resistant surface finish, oil-lubricated enclosed gearbox, and insulation grade Class F, the hoist guarantees dependable service over its long-duty cycle. It's crafted to meet the challenges faced by Indian industries, promising years of reliable use.

FAQ's of Wire Rope Hoist:

Q: What control methods are available for the Wire Rope Hoist?

A: You can operate the hoist using either a pendant control or a remote control, making it convenient for both ground-level and remote operations. Customers may choose the method that best fits their application or switch between them as needed.

Q: How does the hoist ensure safety during lifting operations?

A: Safety is paramount, with electromagnetic fail-safe brakes employed to stop loads instantly in emergencies. Limit switches prevent over-hoisting and excessive lowering, while the IP54/IP55 protection safeguards internal components from dust and moisture.

Q: Where can this hoist be installed and used?

A: Ideal for industrial environments, the hoist can be fixed-mounted or installed on trolleys for flexible movement along beams. It's suitable for factories, warehouses, shipyards, and manufacturing plants across India requiring heavy-duty lifting.

Q: What are the benefits of choosing a heavy-duty S4 duty cycle hoist?

A: An S4 duty cycle rating means the hoist is engineered for frequent or continuous operation, reliably handling repeated starts and stops without overheating-ideal for demanding lifting schedules in industrial operations.

Q: What types of loads can this hoist handle, and up to what height?

A: The hoist is capable of safely lifting single or double heavy-duty forged steel hook loads from 0.5 tons up to 30 tons, with maximum lifting heights between 6 to 40 meters, depending on the chosen model.

Q: How is the gear box protected against environmental factors?

A: The gear box is totally enclosed and oil-lubricated, which minimizes contamination from dust or moisture, reduces wear, and extends the lifespan of internal components, ensuring smooth and efficient hoist operation.
